Custom Fabrication of Process Tanks

Palm Technology designs and fabricates tanks and components that are built to provide long term service in an industrial environment. We use corrosion resistant materials to fabricate tanks for applications as diverse as laboratory etch lines up to large tanks for aerospace anodizing lines. Palm matches the application to the material. We have the capability to build a single tank or an entire process line.

Palm Technology fabricates tanks from:
  • Simona Polypropylene
  • Simona PVC and CPVC
  • Simona PVDF and Kynar
  • Carbon and Stainless Steel (316L and 304L)
  • Palm has the latest equipment to fabricate tanks:
  • AXYZ 6012 CNC Router
  • 13-ft Wegener Butt Welder
  • 10-ft Wegener Bender
  • Wegener Extrusion and Hot Gas Welders
  • Miller MIG & TIG Welders
  • Lathes, Mills, 90 Ton Press Brake, CNC Plasma Cutter and Iron working equipment
  • Palm can roll polypropylene 1/8" thick in a 16" diameter up to 1 1/4" thick in a 13-ft diameter.

    Palm Technology finishes tanks with a wide range of instrumentation. Our tanks have customized guarding to prevent damage to sensors, heaters, and heat exchangers. Palm's modular design minimizes installation time, provides the customer with process flexibility and allows for the line to be easily expanded. Our tanks are spark tested at 20,000 volts and water tested to ensure even expansion and that they are defect free before they leave our facility.
